Description
Modernized design and crisp Full HD images. The 22B2H/EU combines a sleek 3-sides frameless panel and VGA and HDMI connectivity. Enjoy working or streaming with wide viewing angles and eye-soothing LowBlue and FlickerFree technologies.
Frameless design
Besides looking modern and attractive, frameless designs enable seamless multi-monitor setups. Your cursor/windows will not be lost anymore in the dark abyss of bezels, when many displays are placed side by side.
FHD Resolution
Want to watch a Blu-ray movie in full quality, enjoy games in high resolution or read crisp text in office applications? Thanks to its Full HD resolution of 1920 x 1080 pixels, this monitor lets you do just that. Whatever you are viewing, with Full HD it will be displayed in rich detail without requiring a high-end graphics card or consuming a lot of your system’s resources.
VA Panel
VA Panels (Vertical Alignment) display deeper blacks and a high contrast for extra vivid and bright images.
HDMI
HDMI (High-Definition Multimedia Interface) is supported by the current gaming consoles, current GPUs, set-top boxes, supporting the HDCP digital content protection system. HDMI 1.3-1.4b versions support up to 144 Hz refresh rate@1080p and 75 Hz@1440p, while HDMI 2.0-2.0b versions support 240Hz@1080p, 144Hz@1440p and 60 Hz@2160p (4K).
Low Blue Light
AOC Lowblue Light protects you from harmful blue light which, during long sessions, has been shown to cause eye strain, headaches, and sleeping disorders. Our Lowblue Light feature reduces the harmful wavelengths emitted without sacrificing color composition, setting the experience free from the worry of eye damage.
Flicker Free
AOC Flicker-Free Technology utilises a DC (Direct Current) backlight panel, reducing flickering light levels. With eye strain and fatigue absolutely minimized, feel free to enjoy those long, intense gaming sessions in comfort!
Display information
SCREEN SIZE (INCH)
21.5
SCREEN SIZE (CM)
54.61
FLAT / CURVED
Flat
DISPLAY VIEWING AREA (HXW) IN MM
476,64 x 268,11
DISPLAY HARDNESS
3H
PIXEL PITCH
0.2482
PANEL RESOLUTION
1920×1080
RESOLUTION NAME
FHD
ASPECT RATIO
16:9
PANEL TYPE
VA
BRIGHTNESS IN NITS
250
BACKLIGHT TYPE
WLED
REFRESH RATE
75 Hz
RESPONSE TIME GTG
4 ms
STATIC CONTRAST RATIO
3000:1
DYNAMIC CONTRAST RATIO
20M:1
VIEWING ANGLE (CR10)
178/178
DISPLAY COLOURS
16.7 Million
Video Features
DIGITAL SIGNAL FREQUENCY
VGA/HDMI1.4 : 30 -83kHz (H) 50 -76 Hz (V)
FLICKER-FREE
Yes
BLUE LIGHT TECHNOLOGY
Low Blue Light
Cabinet information
BEZEL TYPE (FRONT)
3-sided frameless
BEZEL COLOUR (FRONT)
Black
BEZEL FINISHING (FRONT)
Texture
CABINET COLOUR (BACKSIDE)
Black
CABINET FINISHING (BACKSIDE)
Texture
KENSINGTON LOCK
Yes
VESA WALLMOUNT
100×100
Ergonomic information
TILT
-5/21,5
Power Consumption
POWER SUPPLY
External
POWER SOURCE
100 – 240V 50/60Hz
POWER CONSUMPTION ON (ENERGYSTAR TEST METHOD) IN WATTS
18
POWER CONSUMPTION STANDBY IN WATTS
0.3
POWER CONSUMPTION OFF IN WATTS
0.3
ENERGY CLASS
E
Connectivity information
HDMI
HDMI 1.4 x 1
D-SUB (VGA)
Yes
AUDIO OUTPUT
Headphone out (3.5mm)
Product Dimensions
PRODUCT DIMENSIONS INCL. BASE (WXHXD) MM
388.11(H) x 492.78(W) x 162.94(D)
PRODUCT DIMENSIONS EXCL. BASE (WXHXD) MM
292.68(H) x 492.78(W) x 36.2(D)
PACKAGING DIMENSIONS (WXHXD) MM
370(H) x 550(W) x 120(D)
GROSS WEIGHT INCL. PACKAGE (IN KG)
3.5
NET WEIGHT EXCL. PACKAGE (IN KG)
2.1
