Description
Silence Has A Sequel
- Silencio Design
- Silencio Technology
- Sound Dampening Material
- Seamless Tempered Glass or Sound-Dampened Steel
- Top & Front Ventilation
- Reversible Steel Door
Silencio Design
The Silencio’s minimalistic design cloaks its complexity. Design elements fine-tuned in form and function result in minimized noise and efficiently maintained system temperatures.
Silencio Technology
Behind the outer panels are pieces of meticulously placed sound dampening material. The development of the Silencio was driven by Sorama’s Cam64—this allowed for the entire sound spectrum to be visually analyzed by source, resonance pattern, and frequency.
With the identification of peaks within certain frequency ranges, fine-tuning the Silencio for the dispersion of resonance was made possible, reducing the prominence of noise generated by system components. Every detail in design optimized the Silencio for thermal efficiency and silence, from the type of material used to its placement.
Sound Dampening Material
The Silencio utilizes a combination of sound dampening materials, from thick soft foam to heavy mass-loaded vinyl, to precisely counter prominent frequencies.
Front Ventilation
The front panel features a recurved vent, directing air in through the front bezel. The curve points downward, taking air in from the bottom, and straightens out to direct air in from either side of the steel front door.
Top Ventilation
For an even higher demand for ventilation, the top panel’s Sound Dampening Cover can be removed for unrestricted ventilation. An optional dust filter for the top panel ventilation is included, allowing the top panel and front panel work in conjunction to cool the system.
Reversible Steel Door
The steel front door features a reversible mounting system, capable of opening in either direction. To prevent vibrations, a softer, thicker material spans the steel structure in conjunction with a hinge system of magnets and rubber stompers.
Silencio Fans
Two Silencio FP 120mm PWM fans are pre-installed with rubber padding to reduce noise, featuring specially designed blades that allow both quiet operation and high air pressure.
Versatile HDD Cage
The HDD cage is (re)movable. The cage can be shifted forward to make room for a longer PSU, backwards for additional radiator space, or completely removed if HDD storage is not needed.
Cooling Support
Top:
120 / 140mm x 1 Fans
120 / 140mm x 2 Fans (remove ODD cage)
120 / 240* Radiator
*remove ODD cage
Front:
120 / 140mm x 2 Fans
120 / 140 / 240 / 280* Radiator
*may interfere with HDD mounted below ODD bracket
Rear:
120 x 1 Fan
120 x 1 Radiator
Storage Support
5.25” ODD x 1 (ODD version)
3.5” HDD x 4
2.5” SSD x 4
Clearances
CPU Cooler (Steel): 167mm
CPU Cooler (TG): 166mm
Power Supply:
325mm (w/o front radiator & HDD cage)
140mm (HDD cage in backmost position)
Graphics Card: 319mm
Description
Specification
- Form Factor: Micro ATX
- #Hide#Small Form Factor: No
- Power Supply Wattage: No PSU
- Motherboard Support: “Micro ATX, Mini ITX”
- #Hide#Window(s): No
- Connectors / Controls: 2 x USB 3.2 Gen1 Type-A
1 x 3.5mm Headset Jack (Audio+Mic) - #Hide#5.25 Bay: Yes (5.25 Bay)
- Drive Bays: 1 x 5.25″” Drive Bays
4 x 3.5″” Drive Bays
4 x 2.5″” Drive Bays - Expansion Slots: 4 Expansion Slots
- Cooling System: Included:
Front: 1 x Silencio FP 120mm PWM fan
Rear: 1 x Silencio FP 120mm PWM fanFan Mounts:
Front: 2 x 120 / 2 x 140 mm
Top: 1 x 120 / 140mm OR 2 x 120 / 140 mm (remove ODD cage)
Rear: 1 x 120 mm - .: ”
Radiator Options:
Front: Up to 280 mm*
Top: 120 / 240 mm (240mm requires removal of ODD cage)
Rear: 120 mm*Remove & reinstall ODD bracket to mount 280mm radiator, may interfere with HDD mounted below ODD bracket”
- Colour: Black
- Material: “Steel, Plastic, Sound Absorbing Material
Sides: Sound-Dampened Steel” - Compatibility: “GPU Clearance:
319 mmCPU Clearance:
167 mmPSU Clearance :
325mm (w/o front radiator & drive cage)
140mm (HDD cage in backmost position)
Bottom Mount, ATX PS2″ - Weight/Dimensions: (LxWxH) 418 x 210 x 408 mm (Incl. Protrusions)
(LxWxH) 403.5 x 210 x 400 mm (Excl. Protrusions)
Volume: 33.9L (Excl. Protrusions) - Additional Features: “Sound Dampening Material
Card Reader: Supports SD & MMC Cards
Dust Filters: Front, Top, Bottom
Top & Front Ventilation
Reversible Steel Door
Dust Filters: Front, Top, Bottom
Optional dust filter for top panel ventilation is includedSee Overview for more details”
- Package Weight: 8.2000 kg
- Warranty: 2 Years
