Description
CORSAIR RMx SHIFT Series fully modular power supplies boast a revolutionary side cable interface to keep all your connections within easy reach, for exceptionally convenient 80 PLUS Gold efficient power.
- Innovative Easy-Access Connection Position: Modular connections on the side of the PSU mean easier access for your cables and simpler, cleaner cable management.
- Fully Modular Micro-Fit PSU Connectors: CORSAIR Type 5 Gen 1 micro-fit PSU cables mean you only connect the cables your system needs while taking up less space.
- 140mm Fluid Dynamic Bearing Fan: Utilizes a specially calculated fan curve for high performance, low noise, and superior reliability.
- Intel® ATX 3.0 Certified: Compliant with the ATX 3.0 power standard, supporting the PCIe Gen 5 platform and resisting transient power spikes.
- 100% 105°C-Rated Japanese Electrolytic Capacitors: Premium internal components deliver unwavering power delivery and long-term reliability.
- Modern Standby Compatible: Extremely fast wake-from-sleep times and better low-load efficiency.
- 80 PLUS Gold Certified: Steady power output at up to 90% efficiency, and Cybenetics-certified for lower power consumption, less noise, and cooler temperatures.
- Zero RPM Fan Mode Support: At low and medium loads the cooling fan switches off entirely for near-silent operation.
- Resonant LLC Topology with DC-to-DC Conversion: Provides clean, consistent power and enables use of more energy-efficient sleep states.
- Ten-Year Warranty: Your guarantee of reliable operation that will last across several system builds.
CORSAIR RMx SHIFT Series fully modular power supplies boast a revolutionary side cable interface to keep all your connections within quick reach, for exceptionally convenient 80 PLUS Gold efficient power. With fully modular micro-fit connections and ATX 3.0 compliance, RMx SHIFT makes clean PC builds and upgrades even easier. RMx SHIFT PSUs use Japanese 105°C-rated electrolytic capacitors, for long life and reliability backed by a ten-year warranty. A 140mm fluid dynamic bearing fan utilizes a specially calculated fan curve for high performance and reliability with low noise, while Zero RPM mode support ensures virtually silent operation at low and medium loads. For quiet, efficient, and accessible power, put an RMx SHIFT Series PSU on your side.
Description
Specification
- Form Factor: ATX
- Series: Corsair RMx SHIFT
- Wattage: 1200 W
- Modular: Fully Modular
- Compatibility: ATX12V v2.53
EPS12V v2.92
Intel ATX 3.0 Certified - #Hide#Wattage Range: 1000 – 1250W
- Connectors: “1 x 24-pin ATX (24-pin)
2 x ATX 12V/EPS12V (4+4-pin)
1 x PCIe 5 (12+4-pin) 12VHPWR
4 x PCIe (6+2-pin, dual)
4 x PCIe (6+2-pin)
16 x SATA (Straight)
8 x PATA Connectors” - AC Input: 100 – 240V
- Fan Type: 140mm fan
Supports Zero RPM fan mode - Fan Bearing: Fluid / Hydraulic Bearing
- 80+ Certification: 80+ Gold
- Efficiency: Up to 90%
- MTBF: “100,000 hours”
- Additional Features: See Overview / Video
- Weight/Dimensions: 2.0 kg
180 x 150 x 86 mm - Package Weight: 4.1000 kg
- Warranty: 10 Years
- #Hide#ATX 3.1/3.0: ATX 3.0
