Description
JetStream 28-Port Gigabit Smart Switch with 24-Port PoE+
- 250 W PoE Budget: 24x 802.3at/af-compliant PoE+ ports with a total power supply of 250 W*.
- Full Gigabit Ports: 24x gigabit PoE+ ports and 4x gigabit SFP Slots provide high-speed connections.
- Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)**, Centralized Cloud Management, and Intelligent Monitoring.
- Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
- Static Routing: Helps route internal traffic for more efficient use of network resources.
- Robust Security Strategies: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm control, DHCP Snooping, 802.1X, Radius Authentication, and more.
- Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping.
- IPv6: IPv6 support with dual IPv4/IPv6 stack, MLD snooping, IPv6 neighbor discovery.
Software Defined Networking (SDN) with Cloud Access
Omada’s Software Defined Networking (SDN) platform integrates network devices, including access points, switches and gateways, providing 100% centralized cloud management. Omada creates a highly scalable network – all controlled from a single interface. Seamless wireless and wired connections are provided, ideal for use in hospitality, education, retail, offices, and more.
*PoE budget calculations are based on laboratory testing. Actual PoE power budget is not guaranteed and will vary as a result of client limitations and environmental factors.
**Zero-Touch Provisioning requires the use of Omada Cloud-Based Controller.
Description
Specification
- Rackmountable: Yes
- Managed: Smart
- Number of Ports: 28
- Max RJ45 Transfer Rate: 10/100/1000 Mbps
- #Hide#Max SFP Transfer Rate: GB SFP
- Interface(s): 24 x 10/100/1000 Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)
4 x Gigabit SFP Slots - PoE Ports (RJ45): Standard: 802.3at/af compliant
PoE+ Ports: 24 Ports
Power Supply: 250 W - Bandwidth: 56 Gbps
- Standards and Protocols: “IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3az, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x”
- Power Supply: PoE
Max Consumption:
32.1 W (110 V/ 60 Hz with no PD connected)
308.6 W (110 V/ 60 Hz with 250 W PD connected) - Dimensions: 440 x 220 x 44 mm
- Mac Address Table: 8K
- Packet Forwarding Rate: 41.7 Mpps
- Jumbo Frame: 9KB
- Additional Features: See Overview
- Quality of Service: “Support 802.1p CoS/DSCP priority
Support 8 priority queues
Queue scheduling: SP, WRR, SP+WRR
Port/Flow- based Rate Limiting
IPv6 QoS
Voice VLAN” - Layer Features: “Static Routing
DHCP Relay
DHCP Server
IGMP Snooping V1/V2/V3
Spanning Tree STP/RSTP/MSTP
BPDU Filtering/Guard
TC/Root Protect
Loopback detection
802.3x Flow Control
LLDP, LLDP-MED
802.3ad LACP (Up to 8 aggregation groups, containing 8 ports per group)” - VLAN: Supports up to 4K VLANs simultaneously (out of 4K VLAN IDs)
MAC/Protocol-based VLAN - Access Control: L2–L4 package filtering
MAC ACL
IP ACL
Combined ACL
IPv6 ACL - Security: AAA
Port Security
DHCP Snooping
IP-MAC-Port Binding
IPv6-MAC-Port Binding
ARP Inspection
802.1x and Radius Authentication
SSH v1/v2
SSL v3/TLSv1.2
Broadcast/Multicast/Unknown-unicast Storm Control
Dos Defend - Management: “Omada App
Omada Cloud-Based Controller
Centralized Management
Web-based GUI and CLI management
SNMP v1/v2c/v3 (public MIBs and TP-Link private MIBs)
RMON (1, 2, 3, 9 groups)
CPU Monitoring
Port Mirroring
Firmware Upgrade: TFTP & Web
System Diagnose: VCT
SYSLOG & Public MIBS
Dual Image
EEE” - Environment: “Operating Temperature: 0–50C (32–122F);
Storage Temperature: -40–70C (-40–158F)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing” - Package Contents: TL-SG2428P
Power Cord
Installation Guide
Rackmount Kit
Rubber Feet - Package Type: Retail
- Package Weight: 4.1000 kg
- Warranty: Limited Lifetime
- #Hide#POE: Yes
